Input Volt:100-240VAC 50HZ/60HZ | | | Transition Cut-off Current |
| | | | | | | |
| | | 12.6v/16.8v | | | | |
| | 25.2/29.4/33.6v | | | | |
| | 42v | | | | |
| | 50.4v/54.6v/58.8v | | | | |
Efficiency | 85%
| Leakage A | <0.75mA |
Operating Humidity | 5%-95% RH Non-condensing | Altitude | 2000m |
Operating Temperature | -20℃—+40℃ | Storage Temper | -40℃-+80℃ |
Safety Certifications | |
Suitable battery Type | Lead Acid/LiFePo4/Li-ion/Lipo/Nicd/Nimh/Sodium etc, OEM &ODM |
| Transition for Li battery is 10% of CC, and it can be setted between 5-10%.
(charging time:3-4 hours) |
Transition for Lead Acid battery is 20% of CC, and it can be setted between 15-30%.(charging time:6-8 hours) |
Protection | Over Current, Over Voltage, Over temperature, Short Circuit, Reverse Polarity |
Advantage | Cooling by built-in silent DC fanAluminum case, Robust, Elegant and Reliable
Low surge current, flyback input full voltage, small output voltage ripple
Benbv Tech co.,ltd |
Package Contents | *1xbattery charger
*1xInput Wire
*1xOutput Fuse
*1xUser Manual |
